Core Technology:

Employs a core technology system of variable frequency speed control, PLC intelligent control, and multi-pump parallel operation. Optional negative pressure superposition technology is available. With "constant pressure stability + energy saving and consumption reduction + intelligent operation and maintenance + safety and reliability" as its core design goals, the system is optimized to address the characteristics of "large peak-valley fluctuations in water consumption, large differences in water pressure demand, and high requirements for continuous water supply." It features multiple protection functions including overload, undervoltage, water shortage, and leakage protection, and has strong resistance to load shocks.

Core Product Advantages

1. Stable Water Pressure and Superior User Experience: Variable frequency speed control matches water consumption changes in real time, ensuring water pressure fluctuations ≤ ±0.02MPa. This completely solves the problems of fluctuating water pressure and insufficient water supply in high-rise buildings, simultaneously meeting the water needs of different pressure levels for domestic, industrial, and fire-fighting purposes.

2. Significant Energy Saving and Consumption Reduction: Compared to traditional constant-speed water supply equipment, energy savings can reach 30%-60%. The negative pressure-free superimposed pressure model can directly utilize the residual pressure of the municipal pipe network, further reducing energy consumption and avoiding energy waste.

3. Small Footprint, Suitable for Confined Spaces: Adopting a modular integrated design, the water pump unit, variable frequency control cabinet, pipeline valves, instrument monitoring, and other units are highly integrated onto a skid, saving more than 70% of the footprint compared to traditional water supply facilities, eliminating the need for a separate pump house.

4. High degree of automation and low maintenance cost: Equipped with a PLC + touch screen fully automatic control system, it achieves fully automated operation of the entire process, including pump start-up and shutdown, speed adjustment, fault alarm, and data recording. It supports remote monitoring and mobile APP maintenance, requiring no dedicated personnel for 24-hour on-site duty, only periodic inspections.

5. Flexible selection, covering all needs: Multiple standardized models are available, with water supply capacities ranging from 1-500 m³/h and water pressures from 0.2-1.6 MPa (customizable). Pump materials include cast iron and 304/316 stainless steel; control cabinets are available in standard and explosion-proof types, adaptable to different budgets and usage requirements.

6. Short installation cycle and minimal on-site work: The equipment is pre-assembled, debugged, and pressure tested at the factory. On-site work only requires foundation leveling, inlet and outlet pipe connection, and electrical connection before it can be put into use, significantly shortening the on-site construction cycle and fitting the project schedule for various projects.

7. Safe and hygienic, no secondary pollution: The fully enclosed pipeline design prevents mosquitoes, dust, and debris from entering; the flow-through components are made of food-grade stainless steel to avoid secondary water pollution and meet drinking water hygiene standards.

Suitable Scenarios:

Temporary water supply for infrastructure construction camps, water supply for offshore operation platforms, water supply for field exploration bases, production water supply for industrial plants, domestic water supply for commercial buildings, secondary water supply for residential communities, temporary municipal water supply, centralized water supply in remote areas, fire-fighting booster water supply, etc.
